What is a dental compressor?

Views:2     Author:Site Editor     Publish Time: 2020-04-24      Origin:Site

What is a dental compressor?


Modern medical field cannot leave dental compressor, so do you really know what is a dental compressor?This article will introduce dental compressor from the following aspects:Definition of dental compressor,Advantages of dental compressor,Function of dental compressor,Performance characteristics of dental compressor,Working principle of dental compressor.


The following knowledge points are listed below:


1. Concept of dental compressor:

2.Advantages of dental compressor:

3.Function of dental compressor.

4.Performance characteristics of dental compressor

5.Working principle of dental compressor



1.Concept of dental compressor:


Dental compressor is widely used in the medical field to provide sufficient and clean air for the medical equipment that needs air source.Dental compressor is one of the main mechanical power equipment in many clinics and hospitals.Strict implementation of the dental compressor operating procedures, not only to extend the service life of the dental compressor, but also to ensure the safety of the compressor operators.


2.Advantages of dental compressor:


The output gas is dry, absolutely oil-free, with low noise, large displacement, high exhaust pressure, long service life, reliable performance, easy to move, small size, beautiful appearance and so on.It is the most ideal air source for domestic and imported breathing maneuvers, pneumatic dental drills and oral sprays.


3.Functions of dental compressor.


(1)Automatic identification of external air source

(2)To the pressure and temperature of the abnormal sound and light alarm, overlimit active shutdown protection

(3)Complete internal pressure protection system can ensure the safety of the dental compressor

(4)Efficient oil-free dental compressor movement and multi-stage air filtration, dehydration, cooling system design, to ensure that the output gas to meet the medical compressed air indicators

(5)Unique internal structure design and efficient sound absorption isolation layer, can ensure the dental compressor working noise less than 50 db

(6)Dental compressor can minimize the impact of flow variation on system pressure and ensure high flow output, while meeting the needs of instantaneous large flow



4.Performance characteristics of dental compressor


(1)The output compressed gas is clean, oil-free and dry.

(2)The machine runs smoothly with low noise.

(3)Automatic water distribution.

(4)Timing function.

(5)The structure is tightened.

(6)Long service life, free of maintenance.

(7)Resistance to corrosion.



5.Working principle of dental compressor


Dental compressor is a miniature oil-free reciprocating piston compressor, which is driven by a single shaft of the motor with a crank rocker mechanism with a wrong Angle of 180°. The main motion pair is a piston ring, and the supporting motion pair is an aluminum alloy cylinder.Through the reciprocating motion of the crank rocker, the travel volume of the cylinder is changed periodically by the compressor, and the travel volume of each group of cylinders will change in opposite directions twice each week when the motor runs.To axial movement, when the piston cylinder volume increases, as the negative pressure in cylinder, the atmospheric pressure is greater than the pressure in the cylinder, air through the intake valve into the cylinder, at this time for the suction process: when the piston movement to cover, into the gas in the cylinder is compressed, the rapid increase of the pressure inside the gas when the pressure is greater than exhaust cavity pressure, exhaust valve is opened, the exhaust process at this time.The structure of single shaft and double cylinder makes the dental compressor discharge twice as much as that of single cylinder. The vibration and noise generated by dental compressor are well improved due to the crank and rocker mechanism with the wrong Angle of 180°, and the overall structure is more compact.


Dental compressor is one of the main mechanical power equipment in many clinics and hospitals.Strict implementation of the dental compressor operating procedures, not only to extend the service life of the dental compressor, but also to ensure the safety of the compressor operators.If you want to know more professional knowledge about  dental compressor and high quality dental compressor, choose our company, you will not be disappointed.
