Features
- Easy to use
- Powerful motor with 5.5 Ncm torque
- Wide speed range: 300 up to 40,000 rpm at the motor
- Precise torque limitation: 5 to 70 Ncm
- Automatic thread cutter function
- Motor with cable is thermo washer disinfectable and sterilizable
Specification
• Max. torque at the rotary instrument (in program 4): 70 Ncm
• Mains voltage: 220 – 240 V, 50 / 60 Hz
• Max. mechanical output power: 70 W
• Max. torque at the motor: 5.5 Ncm
• Motor speed range in the nominal voltage range: 300 – 40,000 min-1
• Intended transmission instruments Program 4 and 5: ISO connection 3964 (DIN 13.940), transmission ratio
1:1, 20:1 exclusively with WI-75 or WS-75 models
• Length of motor cable: 1.8 m
• Coolant flow rate at 100 %: min. 90 ml/min
• Foot control: yes
• Dimensions: H100 x W235 x D240 mm
English
Dental Implant surgical machine without LED
