Dental Intraoral Camera LCD Holder

Dental Intraoral Camera LCD Monitor Holder for Most of Dental Chair Very Strong Support M-22

Advantages:

This holder can hold any size LCD monitor to most of the dental unit

The LCD position can be adjusted.

With humanistic design; much more durable and with a good performance.

There are 2 black foam in the package for filling in case the diameter is too thin.

Column diameter is 45-53mm

Specification:

Material:speical plastic

fix:any size led or lcd monitor

fix:most of dental unit,universal

weight:0.8kg

Note:

*Due to there are 2 black foam in the package, if your column diameter is more thin, you can add one or two black foam inside the holder, the Column diameter is 53mm, and the thickness of one black foam is 2mm.

Instrution:

1.Install the bracket onto the holder with the gasket.

2.Connect the bracket to installed plate with the NO.1 bolts.

3.Connect the plate to the LCD.

4.You must use No.3 bolts to install the camera-hand piece holder, the distance can be adjusted according to the size of LCD.

Packing list:

1x bracket

Kindly Reminder

*This holder can hold any size LCD monitor to most of the dental unit(if the diameter of the column diameter is 45-53mm).
