Dental Two in One Bone Surgery Unit And Implantation

Dental Two in One Bone Surgery Unit And Implantation

Implant Scalpel 2-in-1 Technical Parameters

Implant Main Unit:

Input Power: AC 220V; Frequency: 50Hz

Power Consumption: 120W

Operating Mode: Short-time Operation

Waterproof Rating: IPX4 (Foot Switch)

Dimensions: W283.2xD235.5xH140

Water Flow Rate: 5-level control; Maximum cooling water flow rate >

135ml/min

Transmission Ratio: 20:1, 1:5, 1:1 (3 options)

Wireless Foot Pedal Control Mode

7-inch Large TFTY High-Definition Screen

8 Program Control Modes (Positioning, Drilling, Reaming, Tapping,

Implant Placement, Healing Cap Placement, Free Application, Rinsing)

Program selection via touch or foot control.

Real-time Torque and Speed ​

​

Display

Motor:

Maximum Speed: 40000r/min

Maximum Torque: 80N.cm (with 20:1 bending mechanism)

Motor Handle with High-Brightness LED Light

One-Button Panel Switching Function (Switch between Scalpel and

Implant Functions)
