OSA-IST-M002
OSAKADENTAL
9018499000
Dental Equipment Dental Implant Stability Meter
It is a stability measuring device that uses tapping method , which mea - sures the time of the Tapping Rod of the device contacting the implant for dentistry and dental implantology or oral cavity, or abutment, to measure the stability of the placed implant. The result of the measure - ment is displayed in isT Scale (implant stabilityTest) , which is the n umer- ical representation of the Implant stability Test (isT) value, and higher scale represents greater implant stability or lower implant mobility.
Characteristics
1.Convenient usage due to small and light design
2.Easy to use due to simple controlling method
3.Fast measuring time less than 3 seconds
4.Safe measurement due to slight tapping technique and auto safety system (tapping stops after tapping twice when osseointegration is unstable, otherwise taps up to 6times. )
5.Available to check possibility of implant failure at in earlier stages.
Technical specifications
1. protection type against electrical shock: class Il
2. protection degree against electrical shock: Type B
3. Rechargeable lithium battery:Battery model:1 6340, Battery capacity: 850mAh
Battery has over-voltage, over current and short circuit protection
4.Adapter
Input:100 - 240v~ 50/60Hz
output: 5v 1A
5.work condition:Environmenttemperature: +5 c to +40ec
Relative humidity: 10% ~ 93%
Atmosphere pressure: 70kpa to 106kpa
6.operation Mode : continuous operation
