OSA-F011
OSAKADENTAL
(standard/Torque head)
Main features:
1.self-sufficient power system instead of extra supply
2.clear view with day-light LED illumination
3.triple spray
4.push button system
Advantages:
You do not need a fiber optic source or any special kind of wiring or attachment for this handpiece.
Just connect it to your handpiece hose, step on the pedal, and the light comes on automatically.
There is a very small electric generator built inside the turbine which powers the LED light.
Descriptions:
1. Dental E-generator LED handpiece
2. Professional LED light source, superior brightness, longevity 10000 hours
3. Unique electric generator, just a little air can generate sufficient power
4. Self-illumination without connecting circuit
5. Perfect stable and reliable performance
6. Push Button cartridge
7. 135°C Autoclavable
8. Triple water spray, omnibearing, more ideal cleaning effect
9. High-grade material with a stylish design
10. Warranty: one year for handle; six months for cartridge
Technical Parameter:
1. Head: standard head
2. Air Pressure At The Back End Of Handpiece:250KPa--300KPa(300KPa preferred)
3. Air Pressure At The Gauge In The Dental Unit:277-316 KPa (2.8-3.2 kgf/cm2)
4. Water Pressure:198Kpa (2 kg)
5. Rotation Speed:300,000-450,000 rpm
6. Head Hight:14.5 mm( standard )
7. Head Diameter:φ12.5 mm( torque ) φ11.2 mm( standard )
8. Chuck Type: push button
9. Bur Applicable:φ1.59mm~φ1.6mm×21mm~23mm (diameter×length)
10. Noise:≤60dB
(standard/Torque head)
Main features:
1.self-sufficient power system instead of extra supply
2.clear view with day-light LED illumination
3.triple spray
4.push button system
Advantages:
You do not need a fiber optic source or any special kind of wiring or attachment for this handpiece.
Just connect it to your handpiece hose, step on the pedal, and the light comes on automatically.
There is a very small electric generator built inside the turbine which powers the LED light.
Descriptions:
1. Dental E-generator LED handpiece
2. Professional LED light source, superior brightness, longevity 10000 hours
3. Unique electric generator, just a little air can generate sufficient power
4. Self-illumination without connecting circuit
5. Perfect stable and reliable performance
6. Push Button cartridge
7. 135°C Autoclavable
8. Triple water spray, omnibearing, more ideal cleaning effect
9. High-grade material with a stylish design
10. Warranty: one year for handle; six months for cartridge
Technical Parameter:
1. Head: standard head
2. Air Pressure At The Back End Of Handpiece:250KPa--300KPa(300KPa preferred)
3. Air Pressure At The Gauge In The Dental Unit:277-316 KPa (2.8-3.2 kgf/cm2)
4. Water Pressure:198Kpa (2 kg)
5. Rotation Speed:300,000-450,000 rpm
6. Head Hight:14.5 mm( standard )
7. Head Diameter:φ12.5 mm( torque ) φ11.2 mm( standard )
8. Chuck Type: push button
9. Bur Applicable:φ1.59mm~φ1.6mm×21mm~23mm (diameter×length)
10. Noise:≤60dB
