TECHNICAL DATA
This machine belongs to type I model B.
Power supply: AC220V, Frequency:50Hz
Input power: 800VA
Blown fuse specifications: Mains power supply: FR1-20
5×20 5A
The dental chair’s continuous loading time<2min
The dental chair’s loading continuance≤ 60%(the dental chair’s working hours/interval)
Gargling water temperature:40±5°C
Foot Switch: ZPX4
Max. rev. of the high-speed Turbine:≥ 300000r/min
Max. output torque≥6g.cm(Air pressure:0.22Mpa)
Max. rev. of the low-speed motor:≥20000r/min
Max. output torque≥10g.cm(air pressure:0.3Mpa)
Input air pressure:0.55-0.6Mpa,
Flux≥50L/min
Input water pressure:0.2-0.4Mpa
Flux≥10L/min
Environmental Temperature:5-40°C
Relative humidity≤80%
Max. Loading of the instrument tray:≤30N
Note: in this machine, the blue tube is for waterway, the white tube is for the working airway,
and control airway.
