Product Description
Code
Name
Code
Name
1
Electric Foot Switch
7
Light Arm
2
Back Rest
8
Dental Light
3
Head Rest
9
X-Ray View
4
Assistant side
10
Instrument Tray
5
Unit Box
11
Hand-piece Hanger
6
Light Stand
12
Dental Chair
V. Installation
1. Preparation
Decide where to install the machine according to the overall arrangement, lighting and availability of the
clinic. Put the machine in a clean, dry, draughty and cool place as good working conditions. Make sure that the
dental chair chassis contacts the even and solid floor. Under the floor box, there must be inlets/outlets for water,
gas and electricity for the machine within the range of 140×120mm. The water inlet pipe and air intake pipe
should be the 8×5 PU pipes. The drainpipe should be the hosepipe atΦ40mm (3/2″). The port of each pipe is about
40mm away from the floor. The input wire should be the 3-core 1mm jacketed cord, about 400mm away from the
floor. And connect the protective ground wire well. For the detailed dimensions, please see Fig. 2.
2. Unpack the Carton for Inspection
Unpack the carton to verify that the whole machine is intact. And check whether the accessories and spare
parts are complete and intact according to the packing list. For any questions, please inquire the dealer or our
company at once.
3. Installation of the Mainframe
Firstly, put the dental chair in the right place. The design of this machine considers the stability of the whole
machine, so the foot-fixing screws are unnecessary. But the dental chair chassis must contact the even and solid
floor for fear of accidents.
In case of rotation or declining of the whole machine due to the uneven floor, one can fasten the six M12
inner hexad flat end fixing screws into the six M10 screwed holes on the dental chair chassis, and make it fully
contact the floor. During the adjustment, please keep the whole machine even and guarantee as many contact
points as possible, so as to ensure the stability of the whole machine.
